Product Parameters：
| Motor | 48V/750W Bridge Motor |
Battery | 48V/40Ah LFP Battery |
| Sensor | Torque Sensor |
Display | LED Color Display |
Frame | Aluminum Alloy/ Steel Frame |
| Lights | Front lights, Rear lights, Indicator/Warning, Brakes lights |
Drive Train | KMC Chain |
Brakes | Hydraulic Disc Brakes |
| Box | Honeycomb Reinforcement Box |
| Fork | Aluminum/Steel Front Fork |
| Gearing | Automatic 3-speed Internal Gearing |
| Box | Honeycomb Reinforecement Box |
| Electric Motor | Motor+Differential |
| Max Electrically Assisted Speed | 25km/h |
| External Dimensions ( L X W X H ) | 2780mm*1000mm*1875mm |
| Box Dimensions ( L X W X H ) | 1310mm*960mm*1500mm |
| Box Interior Volume | 1.8m3 |
| Kerb Weight | 150kg |
| Payload | 200kg |
| Accessories | Canopy |
| Wheelbase | 1800mm |
| Turning Circle | 4.36m |
| Suspension | Trailing Arm With Coilover Damper |
| Intelligent Functions | Rfid / E-abs / Lot |
| Range | 80km |
| Shelf Configuration | Multiple Options Available |
| Wheels | 20''motorad tire |
Specialized Applications:
Last-Mile Smart Logistics
Precision Residental Delivery
Commercial Express Solutions
Retail Supply Chain Optimization
Municipal Service Ecosystems
Product Advantages:
Smart Design for Safety and Comfort
When stationary on an incline, the load sensor and slope sensor measure the real-time data. The control unit calculates the necessary static torque to keep the tricycle stable. If the rollback risk is detected, the system adjusts reverse torque or activates hill-hold braking to ensure safety.
High Performance Hardware
The robust chassis structure provides excellent stability and reliability. Powered by a rear-axle motor and paired with an efficient regenerative system, it delivers enhanced power and extended range.
Intelligent Software
The embedded software platform supports OTA updates and IoT connectivity, enabling continuous upgrades through its wireless extensibility.
Product Applications：
Engineered through years of innovation, LUXMEA Cargo Bike redefine urban transportation with its versatile design, seamlessly adapting to diverse scenarios—from family outings and sightseeing tours to agile logistics and mobile retail. Its innovative carriage and rider position ensure safer, more intuitive handling than conventional tricycles, while allowing riders to maintain closer interaction with passengers and monitor cargo security effortlessly. As cities prioritize environmental solutions and combat traffic congestion caused by motor vehicles, this thoughtfully designed bike has emerged as a stylish, eco-conscious transportation choice that balances practicality with sustainable urban living.
Product Operate Guide:
FAQ：
1. Won't turn on:
Check whether the battery is charged and installed in place, and whether the battery power switch is on.
Properly install the battery to the battery chute contact position and turn on the battery switch.
2. The brake is not sensitive:
Check the brakes for wear. Check that the brake line is not too loose.
Replace the forklift pads and adjust the tightening brake cable.
3. The cargo bike is shaking when riding
Check whether the tire pressure is underpressure, whether the wheel axle is loose, and the item is too high.
Try filling pressure, tighten the axle, reduce the cargo height.
4. The cargo bike made an abnormal noise
Check and find the abnormal noise area, whether there is any foreign object or loose screw.
Remove foreign objects and tighten the corresponding screws.
