| Quantity: | |
|---|---|
Product Parameters：
| Motor | 48V/3000W Bridge Motor |
Battery | 48V/100Ah LFP Battery |
| Sensor | Torque Sensor |
Display | LED Color Display |
| Frame | Aluminum Alloy / Steel Frame |
| Fork | Aluminum / Steel Front Fork |
| Lights | Front lights, Rear lights, Indicator/Warning, Brakes Lights |
Drive Train | Chainless Drive |
Brakes | Hydraulic Disc Brakes |
Box | Honeycomb Reinforcement Box |
| Accessories | Canopy |
| Electric Motor | Chainless Powertrain System |
| Max Electrically Assisted Speed | 25km/h |
| External Dimensions (L X W X H) | 2620mm*1000mm*1870mm |
| Box Dimensions (L X W X H) | 1310mm*960mm*1500mm |
| Box Interior Volume | 1.8m3 |
| Kerb Weight | 200kg |
| Payload | 400kg |
| Turning Circle | 4m |
| Range | 120km |
| Suspension | Trailing Arm With Coilover Damper |
| Shelf Configuration | Multiple Options Available |
| Intelligent Functions | Rfid / E-abs / Lot |
| Wheelbase | 1820mm |
Wheels | 20''motorad tire |
Specialized Applications:
Last-Mile Smart Logistics
Precision Residential Delivery
Commercial Express Solutions
Retail Supply Chain Optimization
Municipal Service Ecosystems
Product Advantages:
Chainless Serial Hybrid Powertrain
The tricycle is equipped with an innovative chainless serial hybrid powertrain, reducing mechanical wear and delivering a sustained 120km range.
Regenerative Braking System
When driving downhill, the regenerative braking system is activated automatically. The motor switches to generator mode, converting kinetic energy into electrical energy for battery recharge. This mechanism maxmizes energy recovery while maintaining safe descent speeds through dynamic torque modulation.
Intelligent Software
The tricycle employs CAN BUS protocol with modular design. OTA and IoT enable remote upgrades and data interaction, laying a solid technical foundation for meeting future functional expansion requirements.
Product Applications：
Engineered through years of innovation, LUXMEA Cargo Bike redefine urban transportation with its versatile design, seamlessly adapting to diverse scenarios—from family outings and sightseeing tours to agile logistics and mobile retail. Its innovative carriage and rider position ensure safer, more intuitive handling than conventional tricycles, while allowing riders to maintain closer interaction with passengers and monitor cargo security effortlessly. As cities prioritize environmental solutions and combat traffic congestion caused by motor vehicles, this thoughtfully designed bike has emerged as a stylish, eco-conscious transportation choice that balances practicality with sustainable urban living.
Product Operate Guide:
FAQ：
1. Won't turn on:
Check whether the battery is charged and installed in place, and whether the battery power switch is on.
Properly install the battery to the battery chute contact position and turn on the battery switch.
2. The brake is not sensitive:
Check the brakes for wear. Check that the brake line is not too loose.
Replace the forklift pads and adjust the tightening brake cable.
3. The cargo bike is shaking when riding
Check whether the tire pressure is underpressure, whether the wheel axle is loose, and the item is too high.
Try filling pressure, tighten the axle, reduce the cargo height.
4. The cargo bike made an abnormal noise
Check and find the abnormal noise area, whether there is any foreign object or loose screw.
Remove foreign objects and tighten the corresponding screws.
